Liam Steel based in Manila, Philippines well known manufacturer and supplier of high-quality steel products for various industrial uses. With a deep focus on innovation and precision, Liam Steel provides superior materials customized to suit client requirements. Among their high-end products is the Alloy Steel Grade 91 Coil, with its enhanced strength, corrosion resistance, and resistance to heat, making it suitable for power generation plants, chemical plants, and structural uses. Liam Steel provides the best quality and satisfactory service, cementing its position as a reliable industry provider.
Alloy Steel Grade 91 Coil consists mainly of chromium (8-9.5%), molybdenum (0.85-1.05%), and vanadium (0.18-0.25%), with carbon, manganese, silicon, and trace elements adding to its properties. It has superior mechanical strength with tensile strength of 585 MPa, yield strength of 415 MPa, and good elongation of 20%. Due to the excellent creep resistance, thermal stability, and corrosion resistance, the alloy can be suitably used for applications at high temperature in power stations, petrochemical processes, and boilers that provide extended life and increased efficiency.
| Specifications | ASTM A387 / ASME SA387 |
| Standard | ASTM, ASME and API |
| Thickness | 4.0mm – 100mm |
| Specialize | Shim Sheet, Perforated Sheet, B. Q. Profile. |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade | ASTM A387 GR.91 |
| Grade | C | Ni | Mn | S | V | Al | Si | Nb | Cr | Mo | Nitrogen | P |
| A387 GR.91Â | 0.06-0.15 max | 0.43 max | 0.25-0.66 max | 0.012 max | 0.16-0.27 max | 0.05 max | 0.18-0.56 max | 0.05-0.11 max | 7.90-9.60 max | 0.80-2.10 max | 0.025-0.080 max | 0.025 max |
| Grade | A387 GR.91 CL.2 | |||
| A387 GR.91Â | Thickness mm | Yield Min Mpa | Tensile Mpa | Elongation Min % |
| t≦50 | 415 | 585-760 | 18 | |
| 50<t≦200 | – | – | – | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel based in Manila, Philippines is a trusted manufacturer and supplier for Alloy Steel Grade 91 Coils of great quality. In fact, we have earned our reputation for providing a variety of top-notch steel products-such as Structural Steel, Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel-with emphasis on Structural Steel Sheets and Plates. Basic product lines include a complete range of Pipes, Tubes, Flanges, Forged Fittings, Bars, and other forms. Jaxon Steel is committed to its delivery and customer service, thus ensuring that they procure the best raw materials to guarantee high strength and durability with performance specifically for critical industrial applications. Contact us anytime for your Structural Steel Sheet and Plate needs!
Alloy Steel Grade 91 Coil finds a broad application base in high strength, heat-resistance, and corrosion-resistant industry applications. Main applications are seen in the power plant component production, i.e., boilers, heat exchangers, pressure vessels, on account of good creep strength even at high temperature. It finds applications in the oil and gas industries for pipeline and fittings in extreme conditions as well. It is also used in chemical processing equipment and construction structural applications to provide durability and reliability under harsh conditions.
Liam Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Manila, Philippines.
