Liam Steel is a reputable manufacturer and supplier located in Manila, Philippines, with a focus on **ASME SA 387 Grade 5 Class 1/2 Sheets and Plates**. The company has built a solid reputation for providing top-notch alloy steel plates that adhere to international standards for pressure vessels and high-temperature applications. These plates are crafted to deliver exceptional strength, thermal stability, and resistance to oxidation and corrosion, even at elevated temperatures. Thanks to their precision engineering and cutting-edge manufacturing techniques, Liam Steel guarantees that its SA 387 Grade 5 plates will perform reliably in tough industrial settings like refineries, petrochemical plants, and power generation facilities.
**ASME SA 387 Grade 5 Class 1/2 Sheets and Plates** are primarily made from chromium-molybdenum alloy steel, featuring around 5% chromium and 0.5% molybdenum. This unique blend offers remarkable heat resistance, strength, and protection against corrosion. They boast a minimum tensile strength ranging from 415 to 585 MPa, along with solid yield strength, depending on the class. These plates excel in creep resistance and toughness at high temperatures, ensuring a long service life and consistent performance in high-pressure situations. The main distinction between Class 1 and Class 2 lies in their mechanical properties, with Class 2 providing slightly greater strength.
| Standard | ASTM A387 / ASME SA387 |
|---|---|
| Width | 1000mm-3000mm |
| Thickness | 1.0mm – 200mm |
| Production | Hot-Rolled (HR) / Cold-Rolled (CR) |
| Grade | C | Si | Mn | P | S | Cr | Mo |
| A387 GR.5 CL.1 | 0.15 max | 0.55 max | 0.25-0.66 max | 0.035 max | 0.035 max | 3.90-6.10 max | 0.40-0.70 max |
| Grade | A387 GR.5 CL.1 | |||
| A387 GR.5 CL.1 | Thickness mm | Yield Min Mpa | Tensile Mpa | Elongation Min % |
| t≦50 | 205 | 415-585 | 18 | |
| 50<t≦200 | – | – | – | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality ASME SA 387 Grade 5 Class 1/2 Sheet and Plates​ in Manila, Philippines. We specialize in premium steel products, including Alloy Steel, Carbon Steel, Mild Steel and Galvanized Steel, with a strong focus on Carbon Steel Sheet and Plates. Our extensive inventory also includes Pipes, Tubes, Flanges, Forged Fittings and Bars. Committed to fast delivery and exceptional customer service, we use only the finest raw materials to ensure superior strength, durability and performance for critical industrial applications. Contact us today for all your ASME SA 387 Grade 5 Class 1/2 Sheet and Plates​ needs!
**ASME SA 387 Grade 5 Class 1/2 Sheets and Plates** find extensive use in industries where components face high pressure and temperature conditions. They are perfect for crafting boilers, heat exchangers, pressure vessels, and reactors in refineries and chemical processing facilities. In the power and energy sectors, they are utilized for steam piping, gas turbines, and superheaters. Their outstanding weldability, durability, and resistance to oxidation and scaling make them suitable for both onshore and offshore applications. These plates are designed to ensure safety, reliability, and long-lasting performance in critical industrial environments.
Liam Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Manila, Philippines.
