Liam Steel, a top-notch manufacturer and supplier located in Manila, Philippines, specializes in high-quality EN 19 Sheets and Plates designed for outstanding performance in tough industrial settings. Renowned for their remarkable toughness, strength, and wear resistance, these sheets and plates find their place in various sectors, including automotive, power generation, and mechanical engineering. Liam Steel guarantees that every EN 19 product adheres to international quality standards, ensuring exceptional machinability and durability. With cutting-edge manufacturing facilities and a dedication to excellence, Liam Steel delivers EN 19 steel solutions that blend reliability, precision, and long-lasting performance, even in extreme working conditions.
EN 19 Sheets and Plates are made from alloy steels that include chromium (0.9–1.2%), molybdenum (0.2–0.35%), and manganese (0.5–0.8%), with a carefully controlled carbon content of around 0.36–0.44%. This well-balanced composition results in impressive tensile strength, high fatigue resistance, and superior hardness. The material boasts a tensile strength range of 850–1000 MPa and maintains good impact resistance, even post heat treatment. EN 19 steel also showcases excellent toughness, ductility, and wear resistance, making it perfect for components that endure heavy stress, shock, and dynamic loads while ensuring dimensional stability and machinability.
Grade : EN19 Low Alloy Steel Plate
Thickness : from 3mm up to as thick as 150mm
Length :3000mm-18000mm
Supply Condition : As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement.
Impact tested : -52° C
Process of Manufacturing : Hot-Rolled (HR)
| Grade | Mn | Si | C | Cr | P | Ni | S | Mo |
| EN – 19 | .50 – .80 | .10 – .35 | .35 – .45 | .90 – 1.40 | .040 | – | .040 | .20 – .40 |
| Max Stress | 850-1000 n/mm2 | |
| Impact KCV | 55 Joules Min | |
| Hardness | 248-302 HB | |
| Yield Stress | 700 N/mm2 Min | |
| 0.2% Proof Stress | 680 N/mm2 Min | subject to ruling section |
| Elongation | 9% Min |
| GRADE | BS 970 1991 | BS 970 1955 EN | AISI/SAE | Werkstoff |
| EN 19 | 708M40 | EN19 | 4140 | 1.7225 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
EN 19 Sheets and Plates are widely utilized in industries that demand high-strength, durable materials. They are particularly well-suited for crafting automotive parts like gears, shafts, axles, and crankshafts. In the engineering and power sectors, they serve as essential components for machines, bolts, spindles, and couplings. Their outstanding toughness and fatigue resistance make them ideal for applications that involve heavy mechanical loads and impact forces. Additionally, EN 19 plates are employed in the oil & gas, construction, and mining industries for the fabrication of tools, dies, and more.
