Jaxon Steel is a reliable producer and supplier of premium Alloy Steel Gr B6 Fasteners in Manila, Philippines. With a reputation for accuracy and strength, we offer premium fasteners that perform well in high-pressure and high-temperature conditions. Our products are used extensively in oil & gas, petrochemicals, and power generation industries. At Jaxon Steel, we maintain tight quality control and international standards compliance to serve the needs of our clients. Select us for dependable, corrosion-resistant, and high-strength fastening solutions that suit your requirements.
Alloy Steel Gr B6 Fasteners are produced from chromium-molybdenum alloy steel, which has superior strength and corrosion resistance. Their general composition is 5-7% chromium, 0.75-1.25% molybdenum, 0.30-0.50% carbon, with manganese, silicon, phosphorus, and sulfur in controlled proportions. Mechanically, these fasteners have superior tensile strength (minimum 860 MPa), yield strength (minimum 720 MPa), and superior hardness (Rockwell C35 max). They have good wear resistance and toughness and are suitable for high-pressure and high-temperature applications in power plants, oil & gas, and petrochemicals.Â
Specification :Â ASTM A193 / ASME SA193
Dimension :Â DIN, ISO, ASTM, JIS, BS, GB, IS and all International Standards
Size Range :Â M3 – M56 | 3/6″ to 2″ | Custom Sizes
Length :Â 3 mm to 200 mm
| Alloy Steel B6 | C | Mn | Si | P | S | Co | Cr |
| 0.15 max | 1.00 max | 1.00 max | 0.040 | 0.030 | – | 11.50-13.50 |
| Yield Rp0.2 (MPa) | Tensile Rm (MPa) | Impact KV/Ku (J) | Elongation A (%) | Reduction in cross section on fracture Z (%) | As-Heat-Treated Condition | Brinell hardness (HBW) |
| 666 (≥) | 997 (≥) | 42 | 14 | 43 | Solution and Aging, Annealing, Ausaging, Q+T,etc | 121 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
|
Hexagon Bolts / Set Screws |
Stud Bolts |
Hexagon Nuts |
Socket Capscrews |
|---|---|---|---|
|
DIN 931 |
BS4882 |
DIN 934 |
DIN 912 |
|
DIN 933 |
DIN 976 |
BS 1768 |
DIN 6912 |
|
BS 1768 |
BS 1769 |
DIN 7984 |
|
|
UNI 5731 |
BS 1083 |
ANSI B18.3 |
|
|
UNI 5739 |
BS 3692 |
ISO 4762 |
|
|
ISO 4014 |
ISO 4032 |
UNI 5931 |
|
|
ISO 4017 |
ISO 4033 |
BS 2470 |
|
|
BS 1769 |
ANSI B18.2.2 |
BS 4168 |
|
|
BS 3692 |
|||
|
ANSI B18.2.1 |
|||
|
Socket & Slotted Set Screws |
Socket & Slotted Countersunk Screws |
Studs |
Washers |
|
DIN 913 |
DIN 963 |
DIN 938 |
DIN 125 |
|
DIN 914 |
DIN 7991 |
DIN 939 |
DIN 9021 |
|
DIN 915 |
BS 4168 |
DIN 2510 |
BS 4320 |
|
DIN 916 |
BS 1981 |
BS 4439 |
BS 3410 |
|
DIN 551 |
BS 483 |
BS 2693 |
|
|
DIN 553 |
BS 2470 |
Spring Washers |
|
|
DIN 438 |
DIN 127 |
||
|
BS 4168 |
BS 4464 |
||
|
BS 1802 |
Alloy Steel Gr B6 Bolts and other fasteners are used extensively in applications demanding high strength, corrosion resistance, and toughness. They find extensive applications in oil & gas, petrochemical units, power plants, and the marine sector, where they operate at high temperatures and pressures. These fasteners and bolts are ideal for pressure vessels, boilers, heat exchangers, pipelines, and structures. Their high-quality mechanical properties render them the perfect fit for the heavy equipment, automotive, and aerospace sectors. In construction, they provide secure and long-lasting joints in industrial machines, buildings, and bridges. Withstanding wear protects against reliability challenges under extreme conditions, reducing maintenance levels and enhancing efficiency in use.
