Jaxon Steel is a reliable producer and supplier of premium Alloy Steel Gr B7 Fasteners in Manila, Philippines. With a reputation for precision engineering and superior durability, we supply fasteners that are suitable for high-pressure and high-temperature applications in industries like construction, oil & gas, and manufacturing. Our B7 fasteners provide superior strength, corrosion resistance, and reliability, ensuring peak performance in harsh environments. We at Jaxon Steel focus on quality, customer satisfaction, and prompt delivery, hence becoming the preferred fastener choice in the Philippines and globally.
Alloy Steel Gr B7 Fasteners are produced using chromium-molybdenum (Cr-Mo) steel, having mainly carbon (0.37-0.49%), manganese (0.65-1.10%), phosphorus (≤0.035%), sulfur (≤0.040%), silicon (0.15-0.35%), chromium (0.75-1.20%), and molybdenum (0.15-0.25%) as their base elements. The fasteners possess superior mechanical properties in the form of a tensile strength of 125 ksi (860 MPa) and yield strength of 105 ksi (720 MPa). They have a hardness of 35 HRC max for ensuring resistance to wear and durability. Their superior strength, heat resistance, and corrosion resistance qualify them for key industrial uses.
Specification :Â ASTM A193 / ASME SA193
Dimension :Â DIN, ISO, ASTM, JIS, BS, GB, IS and all International Standards
Size Range :Â M3 – M56 | 3/6″ to 2″ | Custom Sizes
Length :Â 3 mm to 200 mm
| Alloy Steel B7 | C | Mn | Si | P | S | Mo | Cr |
| 0.08-0.15 | 1.00 max | 1.00 max | 0.040 | 0.030 | 0.15-0.25 | 11.50-13.50 |
| Grade | Diameter | Tensile Strength | Yield Strength | Elongation | Reduction | Hardness |
| Grade B7 | M64 and under | 860 | 720 | 16 | 50 | 321 HBW or 35 HRC |
| Over M64 to M100 | 795 | 655 | 16 | 50 | 321 HBW or 35 HRC | |
| Over M100 to M180 | 690 | 515 | 18 | 50 | 321 HBW or 35 HRC |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
|
Hexagon Bolts / Set Screws |
Stud Bolts |
Hexagon Nuts |
Socket Capscrews |
|---|---|---|---|
|
DIN 931 |
BS4882 |
DIN 934 |
DIN 912 |
|
DIN 933 |
DIN 976 |
BS 1768 |
DIN 6912 |
|
BS 1768 |
BS 1769 |
DIN 7984 |
|
|
UNI 5731 |
BS 1083 |
ANSI B18.3 |
|
|
UNI 5739 |
BS 3692 |
ISO 4762 |
|
|
ISO 4014 |
ISO 4032 |
UNI 5931 |
|
|
ISO 4017 |
ISO 4033 |
BS 2470 |
|
|
BS 1769 |
ANSI B18.2.2 |
BS 4168 |
|
|
BS 3692 |
|||
|
ANSI B18.2.1 |
|||
|
Socket & Slotted Set Screws |
Socket & Slotted Countersunk Screws |
Studs |
Washers |
|
DIN 913 |
DIN 963 |
DIN 938 |
DIN 125 |
|
DIN 914 |
DIN 7991 |
DIN 939 |
DIN 9021 |
|
DIN 915 |
BS 4168 |
DIN 2510 |
BS 4320 |
|
DIN 916 |
BS 1981 |
BS 4439 |
BS 3410 |
|
DIN 551 |
BS 483 |
BS 2693 |
|
|
DIN 553 |
BS 2470 |
Spring Washers |
|
|
DIN 438 |
DIN 127 |
||
|
BS 4168 |
BS 4464 |
||
|
BS 1802 |
Alloy Steel Gr B7 Fasteners find extensive applications in high temperature and high-pressure usage owing to their superior strength and durability. They are used extensively across sectors like oil & gas, petrochemical, power generation, and construction. Alloy Steel Gr B7 Fasteners are suitable for applications involving pressure vessels, pipes, flanges, and valves in refineries as well as chemical plants. They are also used in heavy machinery, structural framing, and high-stress conditions where reliability is the primary concern. Their exceptional corrosion resistance and heat tolerance make them suitable for extreme conditions, offering safety and long-term reliability in severe industrial and engineering applications.
