Jaxon Steel is a trustworthy manufacturer and supplier of high-quality steel products in Manila, Philippines, specializing in ASTM A537 sheets and plates. Our top-quality steel plates are heat-treated to enhance strength, durability, and resistance to pressure, appropriate for boiler, pressure vessel, and structural use. We deliver customized solutions as per industry standards and client requirements with a commitment to excellence. Our expert team guarantees high quality, competitive price, and prompt delivery, which makes Jaxon Steel a trustworthy option for ASTM A537 steel plates and sheets in the Philippines.
ASTM A537 is a steel possessing superior mechanical properties, which is used in service at moderate to high temperatures. The steel comes in three classes (Class 1, 2, and 3) but varies according to tensile strength. Composition is of carbon (C), manganese (Mn), silicon (Si), phosphorus (P), and sulfur (S), making it possess high tensile and resistant properties. Properties of mechanics have tensile strength ranging from 485-620 MPa for Class 1 and a yield strength of 345 MPa. The material is heat-treated to increase toughness and is suitable for boilers, storage tanks, and pressure vessels used in oil, gas, and petrochemical sectors.
| Condition | normalized |
| grade | ASTM A537 Cl 1 |
| sizes |
|
| Manufacturing method | Hot Rolled |
| certificates | EN 10204 3.1/2.2 |
| Brands | Thyssen, JSPL, Essar, JSW, POSCO, Clabecq, TATA, Dillinger, Uttam, SAIL |
| Uses |
|
| Surface | Painted, Natural |
| TPI | DNV, CE, TUV, KR, CCS, RINA, LR, GL, ABS |
| Mn | 0.70-1.60% |
| C | 0.24% |
| S Max. | 0.025% |
| Ph Max. | 0.025% |
| CU Max. | 0.35% |
| Si | 0.15-0.50% |
| CR Max. | 0.25% |
| NI Max. | 0.25% |
| MOLY Max. | 0.08% |
|  Heat Treatment | Class |  Thickness | Tensile Strength, minimum, ksi [MPa] | Yield Strength, minimum, ksi [MPa] |
|---|---|---|---|---|
| Q & T | Class 3 | 21/2Â in. & under [65 milimeter and under] | 80 ksi [550] | 55 ksi [380] |
| Over 4 inch [Over 100 milimeter] | 70 ksi [485] | 40 ksi [275] | ||
| Over 21/2Â to 4 inch [Over 65 to 100 milimeter] | 75 ksi [515] | 50 ksi [345] | ||
| Q & T | Class 2 | 21/2Â inch and under [65 milimeter and under] | 80 ksi [550] | 60 ksi [415] |
| Over 4 inch [Over 100 milimeter] | 70 ksi [485] | 46 ksi [315] | ||
| Over 21/2Â to 4 inch [Over 65 to 100 milimeter] | 75 ksi [515] | 55 ksi [380] | ||
| Normalized | Class 1 | 21/2Â inch and under [65 milimeter and under] | 70 ksi [485] | 50 ksi [345] |
| Over 21/2Â inch [Over 65 milimeter] | 65 ksi [450] | 45 ksi [310] |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
ASTM A537 plates and sheets are used extensively in the production of pressure vessels and boilers because of their superior strength and toughness. They are well suited for use in high-temperature and high-pressure applications, such as oil and gas storage vessels, heat exchangers, and industrial boilers. The excellent mechanical properties of the material qualify it for use in petrochemical, chemical process, and power generation applications. Additionally, ASTM A537 is used in naval shipbuilding, aerospace, and defence applications where survival under extreme conditions is a requirement. Its weld resistance and corrosion nature also make it an ideal substitute for offshore production platforms and other structural parts operating under extreme conditions.
