Liam Steel, based in Manila, Philippines, is a reputable manufacturer and supplier known for its top-notch High Carbon Steel C55 Sheets and Plates. These products are crafted for outstanding hardness, strength, and wear resistance, making them perfect for applications that require high surface durability and robust mechanical strength. With a commitment to advanced technology and rigorous quality control, C55 Steel Sheets and Plates find their place in various sectors, including industrial, automotive, and engineering. Liam Steel guarantees consistent quality, precise dimensions, and timely delivery, establishing itself as a dependable partner for industries in need of durable, high-performance carbon steel materials for heavy-duty and precision manufacturing tasks.
High Carbon Steel C55 Sheets and Plates are primarily made up of carbon (0.50–0.60%), manganese (0.60–0.90%), and silicon (0.15–0.35%), along with small amounts of phosphorus and sulfur. This specific blend gives the steel its notable hardness and strength after undergoing heat treatment. It boasts a tensile strength ranging from 700 to 850 MPa and a yield strength of about 400 MPa, along with excellent wear resistance and moderate toughness. C55 steel can be hardened and tempered to achieve the desired mechanical properties, making it ideal for producing components that need high surface hardness and dimensional stability.
| Specification | ASTM A830/ASME SA830 |
| Thickness | 2-600mm |
| Width | 4200-11000mm |
| Length | 3000-18000mm |
| Finish | Hot rolled plate (HR) |
| Grade | C | Mn | P | S | Si | Cr | Mo | Ni | Cr+Mo+Ni |
| C55 | 0.52-0.6 | 0.60-0.90 | ≤ 0.045 | ≤ 0.045 | ≤ 0.4 | ≤ 0.4 | ≤ 0.1 | ≤ 0.4 | ≤ 0.63 |
| Mechanical properties a at room temperature in the quenched and tempered condition (+QT) | |||
| Diameter d mm | ≤ 16 | 16-40 | 40-100 |
| Thickness t mm | < 8 | 8-20 | 20-60 |
| Yield Strength Mpa | ≥550 | ≥490 | ≥420 |
| Tensile Strength Mpa | 800-950 | 750-900 | 700-850 |
| Elongation, % | ≥12 | ≥14 | ≥15 |
| Reduction of area ,% | ≥30 | ≥45 | ≥40 |
| C55 EN 10083-2 Number:1.0535 | Comparision of steel grades | |
| JIS G 4051 | S 55 C | |
| DIN 17200 | C 55 | |
| NFA 33-101 | AF70-C 55 | |
| UNI 7846 | C 55 | |
| BS 970 | 070 M 55 | |
| UNE 36011 | C 55 k | |
| SAE J 403-AISI | 1055 | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
High Carbon Steel C55 Sheets and Plates are extensively utilized in industries that demand materials with exceptional hardness and abrasion resistance. Common applications include the manufacturing of industrial tools, knives, springs, blades, gears, axles, shafts, and wear-resistant components. In the automotive sector, they are essential for clutch plates, brake parts, and transmission components. The steel’s impressive strength and machinability also make it a great fit for agricultural machinery, equipment parts, and engineering tools. Thanks to its ability to maintain edge sharpness and endure stress, C55 Steel Plates are a go-to choice for many demanding applications.
Liam Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Manila, Philippines.
