Liam Steel, a top-notch manufacturer and supplier located in Manila, Philippines, specializes in high-quality **SA 516 GR.65N NACE HIC Plates**. These plates are specifically crafted for pressure vessels, boilers, and industrial equipment that operate in sour and corrosive environments. Made from carbon steel, they adhere to ASTM A516/ASME SA516 standards, along with NACE MR0175/ISO 15156 and HIC (Hydrogen-Induced Cracking) compliance, ensuring they stand up to sulfide stress cracking. With a commitment to strict quality control, Liam Steel guarantees consistent mechanical performance and outstanding durability, making these plates a reliable choice for the oil and gas, petrochemical, and offshore industries where safety and long-term performance are paramount.
The **SA 516 GR.65N NACE HIC Plates** are made up of carbon, manganese, phosphorus, sulfur, and silicon, all optimized to strike a perfect balance between strength, toughness, and ductility. They boast a minimum yield strength of 275 MPa and tensile strength that ranges from 450 to 620 MPa, along with impressive notch toughness even in low temperatures. Designed to resist hydrogen-induced and sulfide stress cracking, these plates ensure long-lasting structural integrity in sour service conditions. Manufactured in accordance with ASTM A516 and compliant with NACE and HIC standards, they provide excellent weldability, formability, and dependable performance in challenging environments.
| Grade | ASME SA 516 GR.65N Boiler and Pressure Vessel Steel Plates |
|---|---|
| Width | 1000mm-4500mm |
| Thickness | 5mm-150mm |
| Length | 3000mm-18000mm |
| Supply Condition | As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement. |
| Impact tested | 52° C |
| Tempering | Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F. |
| Applications | Used for weld fabrication of pressure vessels that require improved notch toughness for lower than ambient temperature service. |
| Process of Manufacturing | Hot-Rolled (HR) |
| C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V |
| 0.08/0.20 | 0.4 | 0.9/1.5 | 0.03 | 0.03 | 0.02 | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
| Tensile strength (ksi) | Tensile strength (MPa) | Yield strength (ksi) | Yield strength (MPa) | Elongation in 200mm (min)(%) | Elongation in 50mm (min) (%) |
| 65-85 | 450-585 | 35 | 240 | 19 | 23 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| British Standard | European Norm | ASTM/ASME | DIN |
| BS1501-224-460A/B | EN10028 P295GH | A/SA516 – Grade 65 | DIN 17155 17 MN 4 |
Jaxon Steel is a trusted manufacturer and supplier of high-quality SA 516 GR.65N NACE HIC Plates in Manila, Philippines. We specialize in premium steel products, including Alloy Steel, Carbon Steel, Mild Steel and Galvanized Steel, with a strong focus on Carbon Steel Sheet and Plates. Our extensive inventory also includes Pipes, Tubes, Flanges, Forged Fittings and Bars. Committed to fast delivery and exceptional customer service, we use only the finest raw materials to ensure superior strength, durability and performance for critical industrial applications. Contact us today for all your SA 516 GR.65N NACE HIC Plates needs!
**SA 516 GR.65N NACE HIC Plates** are widely utilized in the construction of pressure vessels, boilers, heat exchangers, storage tanks, and pipelines for sour gas, petrochemical, and offshore applications. They are particularly suited for refineries, chemical processing units, and platforms where resistance to hydrogen-induced cracking is crucial. With their blend of high strength, toughness, weldability, and NACE HIC compliance, these plates are the go-to choice for engineers and fabricators looking for reliable, long-lasting steel solutions in critical sour service environments.
Liam Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Manila, Philippines.
