Liam Steel is a reliable manufacturer and supplier of **A36 Steel Sheets and Plates** based in **Manila, Philippines**. We pride ourselves on delivering top-notch carbon steel solutions that cater to a variety of structural and industrial needs. Our A36 Sheets and Plates are celebrated for their impressive strength, weldability, and versatility, making them perfect for construction, fabrication, and manufacturing projects. Crafted with cutting-edge steelmaking techniques and rigorous quality control, these plates guarantee consistent performance, durability, and reliability. We serve a diverse range of industries, including construction, infrastructure, machinery, and fabrication throughout the Philippines, providing A36 steel products that adhere to international standards and meet the demands of challenging structural and industrial applications.
A36 Steel Sheets and Plates are made from **carbon steel** containing **about 0.25–0.29% carbon, 0.8–1.2% manganese, and trace amounts of phosphorus and sulfur**. They boast **tensile strength ranging from 400–550 MPa** and **yield strength around 250 MPa**, ensuring excellent structural integrity and mechanical performance. These sheets and plates are known for their good weldability, machinability, and formability, making them adaptable for various applications. Their well-balanced mix of strength, toughness, and durability guarantees reliability in construction and fabrication projects.
| Item | Carbon Structural Steel Plates – ASTM A36 |
|---|---|
| Thickness | 5mm-150mm |
| Width | 1000mm-4500mm |
| Length | 3000mm-18000mm |
| Grade | C | Si | Mn | P | S |
| ASTM A36 | 0.25 max. | 0.4 max. | 0.8-1.2 | 0.035 max. | 0.035 max. |
| Tensile strength, kis [MPa] | Yield strength, min, kis [MPa] | Elongation in 8 in. [200 mm], min, % | Elongation in 2 in. [50 mm], min, % |
| 58-80 [400-550] | 36 [250] | 20 | 23 |
| EN | GB | USA | BS | ISO | JIS | IS |
| S235J2G4, Fe360D2 | Q235D | A36 | 40EE | Fe 360B | SM 400 A | IS 226 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Liam Steel is one of the most prominent manufacturers and suppliers of superior quality A36 Steel Sheet and Plate in Manila, Philippines. As experts in steel solutions, we supply a complete spectrum of products like Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our product range comprises Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Known for our reliable delivery and first-rate customer service, we are committed to supplying high-quality steel materials that guarantee durability and excellent performance in numerous industrial applications.
| Thickness (Inches) | Tolerance Over Specified Thickness, For Widths Given, in Inches | |||||||||
| 48 to 59 | 144 to 167 | Thru 47 | 60 to 71 | 96 to 107 | 72 to 83 | 132 to 143 | 120 to 131 | 108 to 119 | 84 to 95 | |
| To under 1/4 | 0.030 | – | 0.030 | 0.030 | 0.030 | 0.030 | 0.040 | 0.030 | 0.030 | 0.030 |
| 1/4 to under 5/16 | 0.030 | – | 0.030 | 0.030 | 0.030 | 0.030 | 0.040 | 0.040 | 0.030 | 0.030 |
| 2 to under 3 | 0.090 | 0.150 | 0.090 | 0.090 | 0.110 | 0.100 | 0.140 | 0.130 | 0.120 | 0.100 |
| 3/8 to under 5/8 | 0.030 | 0.060 | 0.030 | 0.030 | 0.030 | 0.030 | 0.050 | 0.040 | 0.040 | 0.030 |
| 5/16 to under 3/8 | 0.030 | 0.050 | 0.030 | 0.030 | 0.030 | 0.030 | 0.040 | 0.040 | 0.030 | 0.030 |
| 6 to under 10 | 0.240 | 0.270 | 0.230 | 0.240 | 0.240 | 0.240 | 0.240 | 0.240 | 0.240 | 0.240 |
| 3/4 to under 1 | 0.030 | 0.070 | 0.030 | 0.030 | 0.040 | 0.030 | 0.060 | 0.050 | 0.050 | 0.040 |
| 1 to under 2 | 0.060 | 0.110 | 0.060 | 0.060 | 0.070 | 0.060 | 0.100 | 0.100 | 0.080 | 0.060 |
| 3 to under 4 | 0.110 | 0.150 | 0.110 | 0.110 | 0.130 | 0.110 | 0.140 | 0.140 | 0.140 | 0.110 |
| 4 to under 6 | 0.150 | 0.200 | 0.150 | 0.150 | 0.150 | 0.150 | 0.150 | 0.150 | 0.150 | 0.150 |
| ASTM | Thickness (mm) | Weight (kg/m) |
| ASTM A36 | 3 mm | 23.55 kg |
| 4 mm | 31.4 kg | |
| 5 mm | 39.25 kg | |
| 6 mm | 47.1 kg | |
| 8 mm | 62.8 kg | |
| 10 mm | 78.5 kg | |
| 12 mm | 94.2 kg | |
| 16 mm | 125.6 kg | |
| 20 mm | 157 kg | |
| 22 mm | 172.7 kg | |
| 25 mm | 196.25 kg | |
| 28 mm | 219.8 kg | |
| 32 mm | 251.2 kg | |
| 36 mm | 282.6 kg | |
| 40 mm | 314 kg | |
| 45 mm | 353.25 kg | |
| 50 mm | 392.5 kg | |
| 55 mm | 431.75 kg | |
| 60 mm | 471 kg | |
| 65 mm | 510 kg | |
| 70 mm | 549.5 kg | |
| 75 mm | 588.75 kg | |
| 80 mm | 628 kg | |
| 90 mm | 706.5 kg | |
| 100 mm | 785 kg |
| TYPE | ALLOY | IMPERIAL SIZES IN STOCK | ||
|---|---|---|---|---|
| Thickness | Length | Width | ||
| Coil | ASTM A36 | 1/4 Inch, 3/16 Inch, 3/8 Inch, 5/16 Inch, 1/2 Inch, 7/16 Inch | Any | 60 Inch, 48 Inch,72 Inch |
| Cut to Length | 3/16 Inch to 1/2 Inch | Any | 84 Inch to 96 Inch | |
| 3/16 Inch to 1/2 Inch | Any | 96 Inch, 84 Inch | ||
| Hot Rolled (Strip Mill) | 3/8 Inch to 12 Inch | 240 Inch – 480 Inch | 72 Inch to 144 Inch | |
| Discrete (Mill Rolled) | 1/4 Inch, 3/16 Inch, 5/16 Inch | 240 Inch – 480 Inch | 84 Inch to 120 Inch |
Liam Steel’s A36 Steel Sheets and Plates find extensive use in **construction, structural frameworks, bridges, machinery, and general fabrication**. They are particularly suited for **building structures, support beams, plates, welded components, and parts for industrial machinery**, where strength and versatility are crucial. Additionally, these plates are utilized in **infrastructure projects, manufacturing equipment, and heavy-duty fabrication**, offering dependable mechanical performance and long-lasting durability. With Liam Steel’s A36 Steel Sheets and Plates, you can expect high-quality, cost-effective solutions that ensure safety, structural integrity, and efficiency across a wide array of applications.
