Liam Steel, a well-respected manufacturer and supplier located in Manila, Philippines, specializes in high-quality Corten Steel S355J2W Sheet and Plate. These products are crafted to provide exceptional strength and corrosion resistance, making them perfect for outdoor and industrial settings. The unique weathering properties of these steel plates allow them to develop a protective rust layer, which significantly reduces the need for painting and upkeep. Customers appreciate Liam Steel’s S355J2W offerings for their durability, toughness, and resilience against harsh weather conditions. With state-of-the-art manufacturing facilities and rigorous quality control, Liam Steel guarantees that each sheet and plate delivers outstanding structural stability, longevity, and visual appeal for both architectural and industrial uses.
Corten Steel S355J2W Sheet and Plate is an alloy made up of carbon, manganese, phosphorus, sulfur, silicon, copper, chromium, and nickel. The inclusion of copper, chromium, and nickel boosts its resistance to atmospheric corrosion by creating a protective oxide layer. It boasts a minimum yield strength of 355 MPa and a tensile strength ranging from 510 to 680 MPa. This material is known for its excellent impact toughness, even in low temperatures, and its superior weldability. Its perfect blend of strength, ductility, and corrosion resistance makes it an ideal choice for long-term outdoor exposure and heavy structural applications.
Grade : S355J2W Corten Steel Plates
Standard : ASTM A588, A242 / ASME SA588, SA242
Width : 750mm to 1500mm,
Length : 2500mm to 12000mm
Thickness : 3MM to 50mm
Type : Corten Steel / High-Strength Low-alloy Structural Steel
Process : Hot-Rolled (HR)
| Grade | C max | Si max | Mn max | P max | S max | N max | Cr max | Cu max |
| S355J2W | 0.16 | 0.50 | 0.50-1.50 | 0.030 | 0.035 | – | 0.40-0.80 | 0.25-0.55 |
| Grade | Min Yield strength in different thickness | Min tensile strength in different thickness | Elongation in different thickness | ||||||||||||||
| S355J2W | ≤ 16 | > 16 ≤ 40 | > 40 ≤ 63 | > 63 ≤ 80 | > 80 ≤ 100 | > 100 ≤ 150 | ≤ 3 | > 3 ≤ 100 | > 100 ≤ 150 | ≤ 1.5 | > 2 ≤ 2.5 | > 2.5 ≤ 3 | > 3 ≤ 40 | > 40 ≤ 63 | > 63 ≤ 100 | > 100 ≤ 150 | |
| 355 | 345 | 335 | 325 | 315 | 295 | 510- 680 | 470- 630 | 450-600 | 16 | 17 | 18 | 22 | 21 | 20 | 18 | ||
| Grade | DIN |
| S355J2W | 1.8965 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Corten Steel S355J2W Sheet and Plate finds its place in various industries where durability and aesthetic charm are crucial. Its distinctive rust-like look and resistance to atmospheric corrosion make it a favorite for architectural projects, bridges, facades, and outdoor sculptures. In construction and engineering, it’s commonly used for containers, chimneys, railway wagons, and industrial frameworks. The material’s ability to withstand corrosion in diverse weather conditions also makes it suitable for marine, transportation, and structural applications, ensuring a long service life.
