Liam Steel is a top-notch producer and distributor of premium steel products in Manila, Philippines, with expertise in NICRODUR 450 sheets and plates. Our products, renowned for their high strength and resistance to wear, serve industries such as mining, construction, and heavy machinery. With a focus on precision engineering and customer satisfaction, we provide long-lasting and affordable steel solutions. Our NICRODUR 450 sheets and plates guarantee high performance, durability, and reliability, making Liam Steel a reliable partner for industrial steel needs.
NICRODUR 450 sheets and plates consist of carbon, manganese, silicon, chromium, nickel, molybdenum, and boron, which offer superior hardness and strength. They possess high tensile strength, better wear resistance, and impact toughness, with a standard hardness of 450 HBW. Their mechanical properties guarantee durability under adverse conditions. Benefits include longer service life, lower maintenance costs, and improved performance in mining, construction, and heavy machinery. NICRODUR 450 is weldable, cuttable, and machinable with ease, thus being very versatile for use in industry.
Item: NICRODUR 450
Thickness : 5mm to 150mm
Length : 6,000mm to 12,000mm
Width : 1,500mm to 2,500mm
Heat Treatment: N, Q+T
Surface Point : EP, PE, HDP, SMP, PVDF
| Plate Thickness [mm] | C max | Si max | Mn max | S max | P max | Cr max | Ni max | Mo max | B max | CEV max | |
| 8 – 20 | 0,18 | 1,0 | 1,5 | 0,002 | 0,012 | 0,8 | 0,5 | 0,5 | 0,004 | 0,47 | |
| (20) – 40 | 0,19 | 1,0 | 1,5 | 0,002 | 0,012 | 0,9 | 0,5 | 0,5 | 0,004 | 0,56 | |
| (40) – 60 | 0,23 | 1,0 | 1,5 | 0,002 | 0,012 | 1,1 | 0,5 | 0,5 | 0,004 | 0,65 | |
| (60) – 80 | 0,25 | 1,0 | 1,5 | 0,002 | 0,012 | 1,1 | 0,5 | 0,5 | 0,004 | 0,71 |
| Yield strength(minimal), Re [MPa] | Tensile strength, Rm [MPa] | Elongation (minimal), A5 [%] | |
| NICRODUR 450 | 1280 | 1450 | 9 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| 1/8″ | 3/8″ | 3/4″ | 1-1/2″ | 3″ |
| 3/16″ | 1/2″ | 1″ | 2″ | 4″ |
| 1/4″ | 5/8″ | 1-1/4″ | 2-1/2″ | Â |
| *1/8″ thick plate is available in one size only 60″x 120″. The 3/6″ thick plate is available only as 48″ x 144″ and 96″ x 144″. | ||||
| Thickness | Width | Length |
| 4 | 2000 | 6000 |
| 5 | 2000 | 6000 |
| 6 | 2000 | 6000 |
| 6 | 2500 | 6000 |
| 8 | 2000 | 6000 |
| 8 | 2500 | 6000 |
| 10 | 2000 | 6000 |
| 12 | 2000 | 6000 |
| 15 | 2000 | 6000 |
| 16 | 2000 | 6000 |
| 20 | 2000 | 6000 |
| 25 | 2000 | 6000 |
| 32 | 2000 | 6000 |
| 40 | 2000 | 6000 |
| 50 | 2000 | 6000 |
| 60 | 1800 | 3400 |
