Liam Steel, located in Manila, Philippines, has earned a solid reputation as a reliable manufacturer and supplier of top-notch Carbon Steel A192 Tubing. They provide robust and durable solutions tailored for industrial, mechanical, and structural needs. Crafted to meet ASTM A192 standards, these tubes boast remarkable strength, resistance to corrosion, and thermal stability, ensuring they perform consistently even in high-pressure and high-temperature settings. Liam Steel places a strong emphasis on precision manufacturing, rigorous quality control, and exceptional product reliability, making their Carbon Steel A192 Tubing the go-to choice for power generation, chemical, and mechanical projects that demand long-lasting and high-performance materials.
The composition of Carbon Steel A192 Tubing primarily includes carbon (≤0.25%), manganese (0.30–0.60%), phosphorus (≤0.035%), and sulfur (≤0.035%). It showcases impressive mechanical properties, with a tensile strength ranging from 415 to 550 MPa, yield strength between 205 and 345 MPa, and good elongation characteristics. Renowned for its excellent weldability, toughness, and resistance to high-temperature creep, A192 Tubing is perfect for critical industrial applications that require dependable performance, strength, and thermal stability.
| Craft | Cold rolled and Cold drawn |
| Standards | ASTM, ASME and API |
| Length | Min 3 Meters, Max18 Meters, or according to customer’s requirement |
| Thickness | 3-12mm |
| Schedules | SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules |
| Type | Seamless / ERW / Welded / Fabricated |
| Tolerance | Cold drawn pipe: +/-0.1mm
Cold rolled pipe: +/-0.05mm |
| Additional Testing | NACE MR0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc. |
| Form | Round, Hydraulic Etc |
| Origin | European, Japanese, Korean, US, Russian, Indian (Strictly No Chinese Material) |
| End | Plain End, Beveled End, Treaded |
| Specialized in | Large Diameter ASTM A192 Pipe |
| Size | 1/2” NB to 36” NB |
|
C, % |
Mn, % |
Si, % |
P, % |
S, % |
|
0.06-0.18 |
0.27-0.63 |
0.25 max |
0.035 max |
0.035 max |
|
Tensile Strength , MPa |
Yield Strength , MPa |
Elongation, % |
Hardness, HB, WT≥5.1mm |
Hardness, HRB, WT＜5.1mm |
|
325 min |
180 min |
35 min |
137 max |
77 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a leading manufacturer and distributor of high-quality Carbon Steel A192 Tubing in Manila, Philippines. We offer premium steel materials and a diverse range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Committed to fast delivery and exceptional customer service, we source top-grade raw materials to ensure superior strength and durability for demanding industrial applications. Contact us today for all your Carbon Steel A192 Tubing needs!
|
Hot rolled |
Outside Diameter, mm |
Tolerance, mm |
|
OD≤101.6 |
+0.4/-0.8 |
|
|
101.6＜OD≤177.8 |
+0.4/-1.2 |
|
|
Cold Drawn |
Outside Diameter, mm |
Tolerance, mm |
|
OD＜25.4 |
±0.10 |
|
|
25.4≤OD≤38.1 |
±0.15 |
|
|
38.1＜OD＜50.8 |
±0.20 |
|
|
50.8≤OD＜63.5 |
±0.25 |
|
|
63.5≤OD＜76.2 |
±0.30 |
|
|
76.2≤OD≤101.6 |
±0.38 |
|
|
101.6＜OD≤177.8 |
+0.38/-0.64 |
|
|
Hot rolled
|
Outside Diameter, mm |
Tolerance, % |
|
OD≤101.6, WT≤2.4 |
+40/-0 |
|
|
OD≤101.6, 2.4＜WT≤3.8 |
+35/-0 |
|
|
OD≤101.6, 3.8＜WT≤4.6 |
+33/-0 |
|
|
OD≤101.6, WT>4.6 |
+28/-0 |
|
|
OD>101.6, 2.4＜WT≤3.8 |
+35/-0 |
|
|
OD>101.6, 3.8＜WT≤4.6 |
+33/-0 |
|
|
OD>101.6, WT>4.6 |
+28/-0 |
|
|
Cold Drawn
|
Outside Diameter, mm |
Tolerance, % |
|
OD≤38.1 |
+20/-0 |
|
|
OD>38.1 |
+22/-0 |
You’ll find Carbon Steel A192 Tubing widely utilized in power plants, boilers, heat exchangers, and mechanical systems that operate under high pressure and elevated temperatures. It’s particularly suited for steam pipelines, superheaters, and various industrial tubing applications that demand high strength, thermal stability, and corrosion resistance. With its precise dimensional accuracy, outstanding mechanical performance, and adherence to ASTM standards, A192 Tubing is the preferred choice for engineers, fabricators, and industrial developers looking for durable and high-performance carbon steel tubing for their demanding industrial projects.
Liam Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Manila, Philippines.
