Liam Steel, a reputable manufacturer and supplier located in Manila, Philippines, specializes in top-notch Carbon Steel Pipe Caps that are built for reliability, durability, and precision in piping systems. These pipe caps effectively seal the ends of carbon steel pipes, ensuring a leak-proof barrier and safeguarding against external damage or contamination. Crafted to meet international standards, Liam Steel’s pipe caps are perfect for both seamless and welded pipelines. With outstanding strength, resistance to corrosion, and precise dimensions, these fittings are ideal for industries like oil & gas, petrochemical, power generation, and water treatment, delivering long-lasting performance and safety.
Carbon Steel SA178 Tubing mainly consists of carbon (≤0.06%), manganese (0.27–0.63%), phosphorus (≤0.035%), and sulfur (≤0.035%). This blend results in remarkable heat transfer, ductility, and strength. Typically, the tubing provides a minimum tensile strength of 325 MPa and a yield strength of 180 MPa, along with high elongation for better forming and bending capabilities. The seamless, cold-drawn manufacturing process guarantees uniform wall thickness, a smooth surface finish, and excellent mechanical integrity, making SA178 tubing perfect for high-pressure, high-temperature, and critical heat exchange applications.
| Grade: | ASME/ASTM SA179, SA192, SA210, SA178, SA214, API 5L |
|---|---|
| Size: | 1/8” NB TO 24” NB Sch 40/80/160/XXS |
| Form | Round, Square, Rectangular, Coil, U Tube, |
| Length | Single Random, Double Random & Required Length |
| End | Plain End, Bevelled End |
| Type | Seamless / ERW / Welded |
| Certification For Carbon | Mill Test Certificate as per EN 10204 / 3.2B |
| General Requirements | ASTM A 530/A 530M |
| Dimensional Tolerances | ANSI B 36.10 |
| OD Range | 1.250″ – 6.000″ (30-150mm) |
| Wall Range | 0.095″ – 1.000″ (.2.5-25mm) |
| Element | A/SA 178 Gr. A | A/SA 178 Gr. C | A/SA 178 Gr. D |
| C | 0.06 – 0.18 | 0.35 max | 0.27 max |
| Mn | 0.27 – 0.63 | 0.80 max | 1.00 – 1.50 |
| P | 0.035 max | 0.035 max | 0.030 max |
| S | 0.035 max | 0.035 max | 0.015 max |
| Si | – | – | 0.10 min |
| Element | A/SA 178 Grade A | A/SA 178 Grade C | A/SA 178 Grade D |
| Tensile Strength KSI (MPa) | 47 (325) | 60 (415) | 70 (485) |
| Yield Strength KSI (MPa) | 26 (180) | 37 (255) | 40 (275) |
| Elongation min. % | 35 | 30 | 30 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a leading manufacturer and distributor of high-quality Carbon Steel SA178 Tubing in Manila, Philippines. We offer premium steel materials and a wide range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Committed to timely delivery and outstanding customer service, we source the finest raw materials to ensure exceptional strength and durability for demanding industrial applications. Contact us today for all your Carbon Steel SA178 Tubing requirements!
| Grade | Grade A, Grade C, Grade D, BKW, NBK, GBK |
| Available sizes | 4 Inch to 26 Inch, Customized Size Available |
| OD | 12.7mm to 127mm |
| Wall thickness | 1.5mm to 6.0mm |
| Length | 6m-25m, Custom Double / Single Random |
| End Finish | Plain End, Beveled End, Treaded Protected With Plastic End Caps |
| Shape | Round, Coiled, “U” Bend, Rectangular, Hydraulic |
| Manufacturing types |
|
| Common uses & application |
|
| Producing process | Electric-Resistance-Welded |
| Delivery Condition | Annealed, Normalized, Tempered, Heat Treatment, BK, BKS |
| Surface | Varnish |
| Common Supply Terms followed |
|
Carbon Steel SA178 Tubing is extensively utilized in industries that demand efficient heat transfer and dependable mechanical performance. It’s perfect for creating heat exchangers, condensers, boiler tubes, and air preheaters in power plants, chemical processing facilities, and petrochemical industries. Additionally, this tubing finds its place in automotive radiators and pressure vessels due to its superior thermal conductivity and corrosion resistance. Its cold-drawn seamless design ensures precise dimensions and an outstanding surface finish, making SA178 tubing well-suited for challenging industrial environments.
Liam Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Manila, Philippines.
